IdaFlow® Syringe Pumps: The Ideal Solution for Precision Liquid Delivery
The IdaFlow®-Single Syringe Pump, designed specifically for single-channel operation, provides the perfect solution for applications requiring precise liquid dosing and flow control in laboratory and industrial environments. It offers a wide range of syringe capacities (from 1 ml to 60 ml) and material options (glass, plastic, steel), providing a wide flexibility of use. The stepper motor and microcontroller-based structure guarantees high precision for accurate dosing and flow control. With its user-friendly interface and compact design, IdaFlow offers reliability and convenience in liquid dispensing.
Manufactured with high quality materials, IdaFlow®-Single offers long-lasting use and low maintenance costs. This saves time and costs while keeping your workflows uninterrupted and reliable. Set a new standard in liquid delivery with IdaFlow®-Single now and maximize the potential of your business.
| SYRINGES | 1 syringe capacity Glass, plastic, and steel syringes can be attached. Min size: BD 1 ml Max size: BD 60 ml 123 syringes and 13 different brands saved. 20 custom syringes can be saved. |
| FLOW RATE | Min: 17.9 nl/min (with BD 1ml syringe) Max: 84 ml/min (with BD 60ml syringe) |
| MOTOR & CONTROL | Stepper motor Microstepping: 1/2, 1/4, 1/8, 1/16, 1/32, 1/64, 1/256 (depending on linear speed) Motor-to-lead screw ratio: 16/48 Advance per microstep: 0.00651 μm/μstep at 1/256 Max step rate: 333.3 μs/μstep at ½ microstepping Max step rate: 83.33 μs/μstep at ⅛ microstepping Min step rate: 0.39 s/mstep at 1/256 microstepping |
| LINEAR SPEED AND FORCE | Linear speed: 1–150 mm/min Speed resolution: 1 mm/min Linear force: 100–450 N (10–45 kgf) ; (22–100 lbs) |
| DISPLAY | 4.3′ capacitive HDMI LCD User-friendly designed interface with monitoring and control |
| GENERAL | 230 mm (L) × 160 mm (W) × 180 mm (H) Max Working Distance: 140 mm 110V or 220V AC compatible |
| WORKING MODES | Infusion, Withdraw, Infusion-Withdraw, Withdraw-Infusion, Step-step |
| Certification | CE, ISO 9001:2015 |
"Since its installation in our lab in Metallurgical and Materials Engineering Department, the UltraSprayer-Starter system has not only facilitated our ongoing research on solar cells and photocatalyst thin films, but also significantly expanded our research capabilities by enabling the coating of metallic materials. Its ease of use in non-vacuum environments, advanced electronic infrastructure, and suitability for large-area deposition have made it an integral part of both undergraduate and academic research activities. The system has found widespread use among our students and academic staff alike, supporting a diverse range of experimental studies."
“In our research group, we have been actively using IDASONIC’s triple syringe pump in our spray coating system, and we are very satisfied with the results. For our work on semiconductor thin films—particularly oxide- and sulfide-based compounds for optoelectronic circuit elements—the pump’s precise and stable flow control provides a significant advantage. Even at very low flow rates, it ensures consistent and reproducible performance. This reliability has improved both the accuracy of our experiments and the overall quality of the thin films we produce. IDASONIC’s syringe pump has become an essential tool for our research activities.”
“In our research group at Çanakkale Onsekiz Mart University, we are using IDASONIC’s NanoWeaver® Pro electrospinning system for our studies on advanced wound dressings, particularly targeting diabetic wound healing applications. The system’s high precision, stability, and versatility in nanofiber production allow us to design and fabricate functional wound dressings with controlled morphology and tailored properties. This capability significantly enhances the quality and reproducibility of our experimental results. IDASONIC’s NanoWeaver® Pro has become a key technology enabling us to advance our research on innovative solutions for diabetic wound treatment.”
“At the Department of Metallurgical and Materials Engineering, we are using IDASONIC’s UltraSprayer® Pro ultrasonic spray coating system for our research on transparent conductive oxide (TCO) thin films, particularly aluminum-doped zinc oxide (AZO). The system provides excellent control over film thickness, uniformity, and reproducibility, which are critical parameters in our work. With UltraSprayer® Pro, we have been able to produce high-quality AZO coatings with improved optical and electrical properties, directly supporting our research on next-generation functional materials. The device has proven to be a reliable and indispensable part of our laboratory.”
“At COBILTUM, we have been using the NanoWeaver® Pro system in our studies on smart windows, wound dressings, drug delivery systems, and various nanofiber-based coatings. The system offers reliable performance and flexibility, which helps us to work on both materials science and biomedical applications. Its capability to produce uniform nanofibers with controlled properties has made it a practical tool for our research group, supporting different projects in a consistent way.”
With the introduction of the Electrospinning System into our laboratory, we immediately noticed a positive shift in our research workflow. Its compact structure and intuitive controls allowed our graduate students to start experiments quickly without the need for extensive training. The device enabled us to fabricate uniform and reproducible nanofiber structures, which had been difficult to achieve with traditional methods. For research groups engaged in nanomaterials, biomedical applications, or advanced composites, this system stands out as a practical educational platform and an innovative tool that enhances both teaching and research. In addition, the responsive technical support and service provided gave us extra confidence, ensuring that we could focus on our experiments without interruptions.
We are pleased to announce that IDASONIC will participate as the Bronze Sponsor at MEDECO Turkey’s First National Medical Device...
Ultrasonic spray coating is a coating technique that uses high-frequency vibrations to break a liquid solution into a fine mist...
Discover how nanocoating technologies revolutionize hydrogen energy systems. Enhance durability, efficiency, and corrosion resistance with Idasonic’s precision surface engineering solutions.
The pump is ideal for laboratory and industrial applications that require accurate liquid dosing and flow control, such as analytical chemistry, biotechnology, pharmaceuticals, and materials research.
IdaFlow®-Single supports syringe capacities ranging from 1 ml to 60 ml, and can be used with syringes made of glass, plastic, or steel, offering maximum flexibility.
Equipped with a stepper motor and microcontroller-based control system, the pump guarantees high precision in both dosing and flow regulation, ensuring consistent and reproducible results.
The compact form saves valuable lab space, while the intuitive interface makes setup and operation simple. This allows users to focus on their experiments without unnecessary complexity.
